Advanced Surfacing Welding Technology Composite Welded Wear Steel Plate
Overview Product Description Product Parameters High hardness abrasion resistant hardness bimetal plate Atmix wear plate
Send your inquiryDESCRIPTION
OverviewBasic Info.
Width | 1000 1219 1250 1500 2000mm |
Processing Service | Welding, Punching, Cutting, Bending, Decoiling |
Alloy or Not | Is Alloy |
Length | 1000 1500 2000 or as Required |
G Cold Rolled Steel Products, Making SMA | Steel Sheet |
Price Negotiable | Yes |
Thickness | 3.5-16mm |
Logistics | Yes |
Provide Sample | Yes |
Warranty | Yes |
Custom Made | Yes |
Transport Package | Standard or Customized |
Specification | 2+3, 3+3, 5+3, 4+4, 6+5, 8+5, 6+6, 8+6, 8+8, 10+10 |
Trademark | Atmix |
Origin | Rizhao Shandong |
HS Code | 72109000 |
Production Capacity | 5000 Tons Per Year |
Product Description
Product Description
Product name | Wear-resistant plate |
Thickness | 8+4 |
Chemical Composition of C Deposited Metal(%) | 3-3.6 |
Chemical Composition of Si Deposited Metal(%) | 0.5-0.7 |
Chemical Composition of Mn Deposited Metal(%) | 0.5-0.7 |
Chemical Composition of Cr Deposited Metal(%) | 16-18 |
Hardness | 58-62 |
Delivery date | 1-100tons 10days >100tons to be negotiated |
Product Parameters
High hardness abrasion resistant hardness bimetal plateAtmix wear plate are manufactured by welding one or multiple abrasion resistant layers on a medium or low carbon steel base plate. The overlay alloy has a high amount of chromium carbide hard particles.Product Name | Chromium carbide overlay wear plate CCO plate |
Brand | Atmix |
Hardfacing layer | High chromium carbide overlay material |
Chemical Composition | C(%): 3.0-5.0 ,Cr(%): 25-40 |
Microstructure | The carbide (Cr7C3) volume fraction in the weld overlay is above 50% |
Hardness | 58-65 HRC |
Surface Treatment | Hardfacing,clading,coated |
Technique | Hardfacing,open arc welding,submerged arc welding |
Wear Resistance | High wear resistance,30 times higher than low carbon steel and 12 times than heat-treated steel |
Impact Resistance | Medium |
Flatness tolerance | ±3mm/m |
Thickness tolerance | Uniform overlay thickness, with tolerance within 0-0.5mm |
Main Thicknesses | 3+3,4+4, 5+5 6+4,6+5,6+6,6+8 8+4,8+5,8+6,8+7,8+8 10+4,10+5,10+6,10+7,10+8,10+9,10+10,10+20 12+4,12+5,12+6,12+7,12+8,12+10,12+11,12+12 14+6,14+8,14+10,16+6,16+8,16+10 18+6,18+8,18+10,20+5,20+6,20+8,20+10,20+20,30+10,40+10 Customized thickness upon request. |
Plate Size | Open arc welding wear plate:1400*3400mm Submerged arc welding wear plate:1400*3000mm, 1400*3500mm, 2100*3500mm Customized |
Place of Origin | China |
Application | Mining and Construction, Iron&Steel, Cement, Power, Port, Dredging, etc. |
Detailed Photos
Precision equipment processing
High quality
strong wear resistance and good toughness
Thickness:
3+3 5+3 6+4 6+6 8+4 8+8 10+10 12+12 20+20
Certifications
Company Profile
Packaging & Shipping
FAQ
1.Can we supply the sample ?
Yes,we can supply the sample.You can tell us the detail size.2.Can we accept customize?
Yes,we can.We can manufacture as customer's requirement.You can send the CAD or drawing to us.
3.Quality problem?
According to the standard for production.And the products must pass the quality inspection department.We also accept Third Part Inspection.
4.Delivery time?
Prompt delivery for standard size,or under the contract.
5.Payment term?
Under the contract.
6.Other problem?
You can contact our customer service staff to ask help.
